3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast

1
MOQ
9800
Price
3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast
Features Gallery Product Description Chat Now
Features
Specifications
Turning Radius: 2430mm
Basic Infomation
Place of Origin: China
Brand Name: SNSC
Certification: CE ISO
Model Number: FL30
Payment & Shipping Terms
Packaging Details: one 20ft container can hold 4units, one 40HQ can hold 6units
Delivery Time: 25DAYS
Payment Terms: L/C,T/T
Supply Ability: 300 UNITS PER MONTH
Product Description
Product Description

Description of 2ton 2.5ton 3ton 3.5ton 4ton 5ton lpg propane forklift with epa certificate:

  • Japan Nissan Engine or Kubota engine meet EURO V/ USA Tier 4 (EPA)
  • Japan Shimadzu pump and valves,
  • Automatic transmission,
  • 3000-7000mm lifting height Mast,
  • Waterproof overhead guard,
  • Cylinder dust proof proctection,
  • Triangle wider view back mirror,
  • Cooper radiator,
  • Light protection,
  • Fully suspension luxury seat,
  • Hydraulic brake,
  • Warning light,
  • Spare parts and tool box.
Specification
2.5ton Dual Fuel Forklift Price Fork Lift
Specifications
Unit FL30
Features Power type
- LPG
Rated load
kg 3000
Load center
mm 500
Lifting Height
mm 3000
Free lifting height
mm 135
Fork size L*W*T mm 1220*122*40
Mast Tilt Angle Front/Rear . 6/12
Min. Turning Radius
mm 2240
Min. Ground Clearance Mast mm 110
Overhead Guard Height
mm 2070
Front overhang
mm 470
Performance Max. Travelling Speed loaded km/h 19
Max. Lifting Speed loaded/empty mm/s 490
Max. traction force loaded KN 17
Max. Climbing Ability
% 20
Dimension Overall Lenght without fork mm 2570
Overall Width
mm 1160
Mast Lowered Height
mm 1990
Mast Extended Height
mm 4024
Chassis Tyre Front - 7.00-12-12PR
Rear - 6.00-9-10PR
Wheel Base
mm 1600
Wheel Thread Front/Rear mm 970/970
Weight(without load)
kg 3750
Powertrain Battery
V/AH 12/90
Engine Model - NISSAN K25
Rated power KM/r.p.m 37.4/2300
Rated Torque N.m/r.p.m 176.5/1600
No. of Cylinder - 4
Bore x Stroke mm 89x 100
Displacement
L 2.488
Fuel Tank Capacity
L 60
Transmission/Shift
- 1/1 Automatic transmission
Operation Pressure
MPa 17.5
Details Images
3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 0

Original Japanese Kubota engine WG2503

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 1

Electric automatic hydraulic transmission

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 2

Waterproof Overhead Guard

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 3

Seat with safety belt

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 4

LED Warning Light

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 5

Light Protection

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 6

Cylinder Dustproof Protection

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 7

Triangle WIder Rearview Mirror

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 8

Original Japan Shimadzu Hydraulic System

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 9

Duplex or triplex 3000mm - 7000mm Lifting Mast

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 10

High performance Cooper Radiator

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 11

Free spare parts and tool box.(value more than $200 as a gift from SNSC)

Package and Delivery
3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 12
Optional Attachments

We are dedicated to providing forklift VIP solution to meet all kinds of work condition which means SNSC forklift can be customized.

3 Ton LPG Gasoline Forklift with Japanese Engine and 4.5m Triplex Mast 13
