Heavy-duty 3-ton diesel forklift designed for construction, logistics, and industrial applications with 3000 kg lifting capacity.
The SNSC FD30 Diesel Forklift (3 Ton) is built for tough industrial use, offering a 3000 kg load rating and exceptional structural strength. A reinforced mast and heavy-duty chassis ensure stability and safety in challenging environments.
Its diesel engine provides steady torque, smooth mobility, and energy-efficient performance. With its advanced hydraulic controls, operators can easily perform precise lifting and tilting tasks. The ergonomic cabin design helps reduce fatigue during long work sessions.
The engine sends power to the hydraulic pump, creating lifting pressure. Steering and braking systems support reliable and safe movement under load.
| Specifications | Unit | FD30 |
|---|---|---|
| Power | -- | diesel |
| Rated Capacity | kg | 3000 |
| Center of load | mm | 500 |
| Lifting height | mm | 3000 |
| Free lifting height | mm | 145 |
| Forks L×W×H | mm | 1070×125×45 |
| Tilt Forward/Backward | . | 6/12 |
| Min.turning radius | mm | 2600 |
| Min.ground clearance(Mast) | mm | 120 |
| Overhead guard height | mm | 2170 |
| Front overhang | mm | 545 |
| Max.traveling speed(loaded) | km/h | 20 |
| Max.lifting speed(loaded/empty) | mm/s | 470/520 |
| Drawback pull/Grade ability | kN/% | 18/20 |
| Overall length (without fork) | mm | 2825 |
| Overall width | mm | 1230 |
| Mast lowered height | mm | 2065 |
| Mast extended height | mm | 4260 |
| Front Tire | -- | 28×9-15-12PR |
| Rear Tire | -- | 6.50-10-10PR |
| Wheelbase | mm | 1800 |
| Tread width Front/Rear | mm | 1000/970 |
| Curb weight None-load | kg | 4250 |
| Battery Voltage/Capacity | V/Ah | 12/90 |
| Engine Model | -- | XC490BPG |
| Rated power | kw/r.p.m | 37/2650 |
| Rated torque | Nm/r.p.m | 148/2000 |
| Cylinder amount | -- | 4 |
| Bore×Stroke | mm | 90×105 |
| Displacement | -- | 2.54 |
| Fuel tank | L | 70 |
| Transmission | -- | 1/1 automatic transmission |
| Working pressure | MPa | 17.5 |
Japan Isuzu/Mitsubishi engine, Side shifter, Double front tires, Solid tire, Double air filter, Vertical exhaust, fork extension, Cab, Fork positioner.
